Operating the monitor | 41
If you press any button other than the power button, the following messages will
appear depending on the selected input:
Dell P2418HZ
Dell 55 Monitor
P5524Q
Press any key on the keyboard or move the mouse to wake it up.
If there is no display, press the monitor button again to select
the correct input source.
?
No HDMI signal from your device.
If VGA cable is not connected, a floating dialog box as shown below appears. The monitor
will enter Standby Mode after 4 minutes if left at this state.
Dell P2418HZ
Dell 55 Monitor
No VGA Cable
The display will go into Standby Mode in 4 minutes.
www.dell.com/P5524Q
?
P5524Q
If HDMI cable is not connected, a floating dialog box as shown below appears. The monitor
will enter Standby Mode after 4 minutes if left at this state.
Dell 55 Monitor
No HDMI 1 Cable
The display will go into Standby Mode in 4 minutes.
www.dell.com/P5524Q
?
P5524Q
