Dell P56F User Manual

Figure 4. Left View
1. Power port 2. USB 3.0 port with PowerShare
3. HDMI port 4. Thunderbolt 3 port
5. Headset port
Figure 5. Right View
1.
Memory card reader 2. USB 3.0 port with PowerShare
3. Battery status lights 4. Battery status button
5. Kensington security slot
Hot key combinations
The table below details the hot key combinations.
Table 1. Hot key combination
Fn key combination Precision 5520
Fn+ESC Fn Toggle
Fn+ F1 Speaker Mute
Fn+ F2 Volume Down
10 Chassis

Dell P56F Specifications

General

Model	Dell P56F
Category	Laptop
Display Size	15.6 inches
Storage	256GB SSD
Display	15.6-inch
Display Resolution	1920 x 1080
GPU	Intel HD Graphics 620
Operating System	Windows 10 Home
Battery	42Whr
Weight	2.0 kg
CPU	Intel Core i5-7200U
Graphics	Intel UHD Graphics 620
