Replacing the display hinges
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the display hinges with the screw holes on the display
back-cover.
2 Replace the eight screws (M2.5x2.5) that secure the display hinges to the
display back-cover.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 5 to step 21 in Replacing the computer base.
4 Replace the wireless card.
5 Replace the rear cover.
6 Replace the battery.
7 Replace the base cover.
107
