Removing the display cable
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the rear cover.
4 Remove the wireless card.
5 Follow the procedure from step 1 to step 17 in Removing the computer base.
6 Remove the display assembly.
7 Remove the display bezel.
8 Remove the display panel.
Procedure
1 Note the antenna-cable routing and remove the display cable from the routing
guides on the display back-cover and antenna assembly.
112
