Installing the WWAN card
About this task
CAUTION: To avoid damage to the WWAN card, do not place any cables under it.
Steps
1. Insert the WWAN card into the connector on the WWAN daughterboard [1].
2. Connect the WWAN cables to the connectors on the WWAN card [2].
3. Place the WWAN card bracket to secure the WWAN cables to the WWAN card [3].
4. Replace the single (M2x3) screw to secure the WWAN bracket to the WWAN card [4].
