Next steps
1. Replace the battery
2. Replace the
base cover
3. Replace the SD memory card
4. Follow the procedure in
after working inside your computer
VGA daughterboard
Removing the VGA daughterboard
Prerequisites
1. Follow the procedure in before working inside your computer
.
2. Remove the SD memory card.
3. Remove the base cover
.
4. Remove the battery.
Steps
1. Disconnect the VGA daughterboard cable [1], and the display cable from the system board [2, 3].
66 Removing and installing components
