Power adapter
The following table lists the power adapter specifications of your Precision 5560.
Table 17. Power adapter specifications
Description Option one Option two
Type
90 W AC adapter, USB Type-C (with UMA
graphics)
130 W AC adapter, USB Type-C (with Discrete
graphics)
Input voltage
100 VAC-240 VAC 100 VAC-240 VAC
Input frequency
50 Hz-60 Hz 50 Hz-60 Hz
Input current (maximum)
1.50 A 1.80 A
Output current (continuous)
● 20 V/4.50 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
● 20 V/6.50 A
● 5 V/1 A
Rated output voltage
● 20 VDC
● 15 VDC
● 9 VDC
● 5 VDC
● 20 VDC
● 5 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0 °C to 40 °C (32 °F to 104 °F)
Storage
-40°C to 70°C (-40°F to 158°F) -40 °C to 70 °C (-40 °F to 158 °F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Precision 5560.
Table 18. Battery specifications
Description Option one Option two
Battery type
3-cell, 56 Wh "smart" Lithium-ion,
ExpressCharge
6-cell lithium-ion, 86 Wh "smart"
Lithium-ion, ExpressCharge
Battery voltage
11.40 VDC 11.4 VDC
Battery weight (maximum)
0.25 kg (0.56 lb) 0.340 kg (0.75 lb)
Battery dimensions:
Height
7.56 mm (0.30 in.) 7.56 mm (0.30 in.)
Width
77.7 mm (3.06 in.) 77.7 mm (3.06 in.)
Depth
295.20 mm (11.62 in.) 295.2 mm (11.62 in.)
Temperature range:
Specifications of Precision 5560 17
