Dell P91F - Memory installation

Table 22. GPU—Integrated
Controller External display support Memory size Processor
NOTE: You can connect
up to three 4K external
displays or one 5K or one
8K and above displays
using the Thunderbolt 4
(USB-C) ports available
on your Precision 5560
GPU—Discrete
The following table lists the specifications of the discrete Graphics Processing Unit (GPU) supported by your Precision 5560.
Table 23. GPU—Discrete
Controller Memory size Memory type
NVIDIA T1200 4 GB GDDR6
NVIDIA RTX A2000 4 GB GDDR6
Multiple display support matrix
The following table lists the multi-monitor support matrix supported by your Precision 5560.
Table 24. Integrated - Multiple display support matrix
Video ports on Integrated Graphics Card
● One USB 3.2 Gen 2 Type-C port with DisplayPort Alt
Mode
● Two Thunderbolt 4 ports with Power Delivery
Video port on Option Video module
● One USB 3.2 Gen 2 Type-C port with DisplayPort Alt
Mode
● Two Thunderbolt 4 ports with Power Delivery
Number of displays Three 4K external displays or one 5K or one 8K and above
displays using the Thunderbolt 4 (USB-C) ports available on
your Precision 5560
Table 25. Discrete - Multiple display support matrix
Graphics Card NVIDIA Quadro T1200 NVIDIA RTX A2000
Memory 4 GB GDDR6 4 GB GDDR6
Video Ports on system
● One USB 3.2 Gen 2 Type-C port with
DisplayPort Alt Mode
● Two Thunderbolt 4 ports with Power
Delivery
● One USB 3.2 Gen 2 Type-C port with
DisplayPort Alt Mode
● Two Thunderbolt 4 ports with Power
Delivery
Max Displays (direct connect)
4 4
Max Displays (DP multi-stream) 1 1
Number of displays 1 1
Supported Resolution
● 4096x2304 @60 Hz ● 4096x2304 @60 Hz
Total Power 35 W to 95 W 35 W to 95 W
20 Specifications of Precision 5560
