Dell POWEREDGE E11S - Back-Panel Features and Indicators

12 About Your System
Back-Panel Features and Indicators
Figure 1-2. Back-Panel Features and Indicators
Item Indicator, Button, or
Connector
Icon Description
1 Padlock ring Locks the cover release latch.
2 Security cable slot Connects a cable lock to the system.
3 Power supply 305 W power supply.
4 Cable clasp Secures the power cable.
7
8
6
5
9
1
3
10
2
4
