Installing System Components 85
Figure 3-21. Replacing the System Battery
5
To install the new system battery, hold the battery with the "+" facing up,
and aligned to the metal tab on the socket. Press the battery straight down
into the socket until it snaps into place.
6
Close the system. See "Closing the System" on page 46.
7
Enter the System Setup program to confirm that the battery is operating
properly. See "Using the System Setup Program and Boot Manager" on
page 23.
8
Enter the correct time and date in the System Setup program's
Time
and
Date
fields.
9
Exit the System Setup program.
1 positive side of battery connector 2 system battery
3 negative side of battery connector
