Dell PowerEdge R330 - Installing the power supply unit blank

Steps
If you are installing a second power supply unit (PSU), remove the PSU blank in the bay by pulling the blank outward.
CAUTION: To ensure proper system cooling, the PSU blank must be installed in the second PSU bay in a non-
redundant conguration. Remove the PSU blank only if you are installing a second PSU.
Figure 80. Removing the PSU blank
1.
PSU blank 2. PSU bay
Installing the power supply unit blank
Install the power supply unit (PSU) blank only in the second PSU bay.
Prerequisites
CAUTION: To ensure proper system cooling, the PSU blank must be installed in the second PSU bay in a non-redundant
conguration. Remove the PSU blank only if you are installing a second PSU.
Steps
Align the PSU blank with the PSU bay, and push the PSU blank into the chassis until it clicks into place.
