Jumpers and Connectors 165
Jumpers and Connectors
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. See your Product
Information Guide for complete information about safety precautions, working
inside the computer, and protecting against electrostatic discharge.
This section provides specific information about the system jumpers and
describes the connectors on the various boards in the system.
System Board Jumpers
Figure 6-1 shows the location of the configuration jumpers on the system
board. Table 6-1 lists the jumper settings.
NOTE: To access the jumpers, you must remove the expansion cards from
expansion-card riser 1. See "Removing an Expansion Card" on page 92.
