Installing System Components 99
Figure 3-30. Removing and Installing the I/O Panel Assembly
Replacing the I/O Panel Assembly
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 screw on the I/O panel 2 I/O panel assembly
3 alignment stop on chassis 4 I/O panel securing slot
5 holding tab on the chassis
