Item Connector Description
10 P_PSU_CONN PDB connector
11 INT_STORAGE_1 Integrated storage controller card connector
12 INT_STORAGE_2 Integrated storage controller card connector
13 FAN 5 Cooling fan connector
14 FAN 6 Cooling fan connector
15 J_SAS_1A SAS connector
16 J_SAS_1B SAS connector
17 J_SAS_2A SAS connector
18 J_SAS_2B SAS connector
19 J_BP_PWR Hard-drive backplane power connector
20 FAN 4 Cooling fan connector
21 BAT Battery connector
22 J_DVD_PWR Optical drive power connector
23 J_DVD_SATA Optical drive SATA connector
24 FAN 3 Cooling fan connector
25 J_CONTROL_PANEL Control panel connector
26 FAN 2 Cooling fan connector
27 FAN 1 Cooling fan connector
28 P_CMC_2_X16 CMC card connector
29 P_CMC_1_X16 CMC card connector
30 P_FH_RISER2 Expansion-card riser connector
