Table 15. Ops panel functions – 5U enclosure front panel (continued)
Indicator Description Color Status
Top Drawer Fault Amber Constant or blinking: fault present in drive, cable, or sideplane (drawer 0)
Bottom Drawer Fault Amber Constant or blinking: fault present in drive, cable, or sideplane (drawer 10)
ME5084 PSU LEDs
The following table describes the LED states for the PSU:
Table 16. PSU LED states
CRU Fail
(Amber)
AC Missing
(Amber)
Power
(Green)
Status
On Off Off No AC power to either PSU
On On Off PSU present, but not supplying power or PSU alert state. (usually due to critical
temperature)
Off Off On Mains AC present, switch on. This PSU is providing power.
Off Off Blinking AC power present, PSU in standby (other PSU is providing power).
Blinking Blinking Off PSU firmware download in progress
Off On Off AC power missing, PSU in standby (other PSU is providing power).
On On On Firmware has lost communication with the PSU module.
On -- Off PSU has failed. Follow the procedure in Replacing a PSU.
ME5084 FCM LEDs
The following table describes the LEDs on the Fan Cooling Module (FCM) faceplate:
Table 17. FCM LED states
LED Status/description
Module OK Constant green indicates that the FCM is working correctly. Off indicates the fan module has failed. Follow the
procedure in Replacing a fan cooling module
Fan Fault Amber indicates the fan module has failed. Follow the procedure in Replacing a fan cooling module.
ME5084 Ops panel LEDs
The Ops panel displays the aggregated status of all the modules.
Table 18. Ops panel LED states
LED Status/description
Unit ID
display
Usually shows the ID number for the enclosure, but can be used for other purposes, for example, blinking to
locate enclosure.
Power On/
Standby
Amber if the system is in standby. Green if the system has full power.
Troubleshooting and problem solving 35
