System information

Table 19. System Conguration

Option Description

Integrated NIC Allows you to control the on-board LAN controller. The option ‘Enable UEFI Network Stack’ is not

selected by default. The options are:

• Disabled

• Enabled

• Enabled w/PXE (default)

NOTE: Depending on the computer and its installed devices, the items listed in this

section may or may not appear.

Serial Port Determines how the built-in serial port operates.

Choose any one option:

• Disabled

• COM1 (default)

• COM2

• COM3

• COM4

SATA Operation Allows you to congure the operating mode of the integrated hard drive controller.

• Disabled = The SATA controllers are hidden

• AHCI = SATA is congured for AHCI mode

• RAID ON = SATA is congured to support RAID mode (selected by default)

Drives Allows you to enable or disable the various drives on-board:

• SATA-0

• SATA-2

• SATA-3

• SATA-4

• M.2 PCIe SSD-0

Smart Reporting This eld controls whether hard drive errors for integrated drives are reported during system startup.

The Enable Smart Reporting option is disabled by default.

USB Conguration Allows you to enable or disable the integrated USB controller for:

• Enable USB Boot Support

• Enable Front USB Ports

• Enable Rear USB Ports

All the options are enabled by default.

Front USB Conguration Allows you to enable or disable the front USB ports. All the ports are enabled by default.

Rear USB Conguration Allows you to enable or disable the rear USB ports. All the ports are enabled by default.

USB PowerShare This option allows you to charge the external devices, such as mobile phones, music player. This

option is enabled by default.

System setup 19

Dell Precision 3431 Small Form Factor Setup And Specifications
