Table 3. System setup options—Boot options menu (continued)
Boot options
By default, Windows Boot Manager is selected
By default, UEFI Hard Drive is selected
Boot Sequence Displays the boot sequence.
Advanced Boot Options
Enable UEFI Network Stack Enables or disables UEFI Network Stack.
Default: ON
UEFI Boot Path Security Enables or disables the system to prompt the user to enter the Admin
password when booting a UEFI boot path from the F12 boot menu.
Default: Always Except Internal HDD
Table 4. System setup options—System Configuration menu
System Configuration
Date/Time
Date Sets the computer date in MM/DD/YYYY format. Changes to the date take
effect immediately.
Time Sets the computer time in HH/MM/SS 24-hour format. You can switch
between 12-hour and 24-hour clock. Changes to the time take effect
immediately.
Storage Interface
Port Enablement Enables the selected onboard drives.
Default: ON
SATA Operation Configures operating mode of the integrated SATA hard drive controller.
Default: RAID On. SATA is configured to support RAID (Intel Rapid Restore
Technology).
Drive Information Displays the information of various onboard drives.
Enable SMART Reporting Enables or disables Self-Monitoring, Analysis, and Reporting Technology
(SMART).
Default: OFF
Enable Audio Enables or disables all integrated audio controller.
Default: ON
Enable Microphone Enables or disables microphone.
By default, Enable Microphone is selected.
Enable Internal Speaker Enables or disables internal speaker.
By default, Enable Internal Speaker is selected.
USB Configuration Enables or disables booting from USB mass storage devices such as external
hard drive, optical drive, and USB drive.
By default, Enable USB Boot Support is selected.
By default, Enable External USB Ports is selected.
Thunderbolt Adapter Configuration
Enable Thunderbolt Technology Support Enables or disables Thunderbolt Technology Support.
Default: ON
56 System setup
