Feature Specification
• SATA 3 (6 Gb/s)
Drives configurations:
M4700 one internal 2.5 inch SATA HDD/SSD (SATA3) + one mSATA SSD (SATA2)
M6700 two internal 2.5 inch SATA HDD/SSD (SATA3) + one mSATA SSD (SATA2)
Size 1 TB 5400 rpm, 320/500/750 GB 7200 rpm, 320GB 7200 rpm SED FIPS;
128/256/512 GB SATA 3 SSD, 256 GB SATA 3 SSD
NOTE: The size of the hard drive is bound to change. For more
information, see dell.com.
Optical Drive:
Interface
• SATA 1 (1.5 Gb/s)
• SATA 2 (3.0 Gb/s)
Configuration support ODD modules and Air Bay with SATA HDD option
Table 28. Battery
Feature Specification
Type lithium ion
Dimensions (6-cell / 9-cell / 9-cell long cycle life (LCL)):
Depth 82.60 mm (3.25 inches)
Height 190.65 mm (7.50 inches)
Width 20 mm (0.78 inches)
Weight
• 6-cell - 345 g (0.76 lb)
• 9-cell /9-cell LCL - 535 g (1.18 lb)
Voltage 11.10 V
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Non-operating –40 °C to 65 °C (–40 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium ion cell
Table 29. AC Adapter
Feature M4700 M6700
Input voltage 90 VAC to 264 VAC 90 VAC to 264 VAC
Input current (maximum) 2.50 A 3.50 A
Input frequency 50 Hz to 60 Hz 50 Hz to 60 Hz
