Dell Precision Mobile Workstation M4700 - Page 79

Feature M4700 M6700
Output power 180 W 240 W
Output current 9.23 A 12.30 A
Rated output voltage 19.50 VDC 19.50 VDC
Dimensions: 180 W 240 W
Height 30 mm (1.18 inches) 25.40 mm (1 inch)
Width 155 mm (6.10 inches) 200 mm (7.87 inches)
Depth 76 mm (2.99 inches) 100 mm (3.93 inches)
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non Operating –40 °C to 65 °C (–40 °F to 149 °F)
Table 30. Contactless Smart Card
Feature Specification
Supported Smart Cards and
Technologies
• ISO14443A — 160 kbps, 212 kbps, 424 kbps, and 848 kbps
• ISO14443B — 160 kbps, 212 kbps, 424 kbps, and 848 kbps
• ISO15693
• HID iClass
• FIPS201
• NXP Desfire
Table 31. Physical Dimension
Physical M4700 M6700
Height 32.70 mm (1.28 inches) 33.10 mm (1.30 inches)
Width 376 mm (14.80 inches) 416.70 mm (16.40 inches)
Depth 256 mm (10.07 inches) 270.60 mm (10.65 inches)
Weight (Minimum) 2.79 kg (6.15 lb) 3.52 kg (7.77 lb)
Table 32. Environmental
Feature Specification
Temperature range:
Operating 0 °C to 40°C (32 °F to 104°F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity (maximum):
Operating 10 % to 90 % (non-condensing)
Storage 5 % to 95 % (non-condensing)
79
