Dell R210 II

Dell PowerEdge R210 II Technical Guide 45
Non-Mixed Drives,
all SATA, all SSD,
or all SAS
Config
Type
Configurations
# Name
Description
Min HDD
Max
HDD
3
MSTR1CBL
Embedded SATA SW RAID (PERC S100)—RAID 1
2
2
SAS/SATA
RAID
4
ASSR0CBL
Add-in SAS/SATA RAID card, RAID 0 (PERC S300)
with 2 hard drives
2
2
5
ASSR0CBL
Add-in SAS/SATA RAID card, RAID 0 (PERC S300)
3
4
6
ASSR1CBL
Add-in SAS/SATA RAID 1 (PERC S300)
2
2
7
ASSR5CBL
Add-in SAS/SATA RAID card, RAID 5 (PERC S300)
3
4
8
ASSR10CBL
Add-in SAS/SATA RAID card, RAID 10 (PERC S300)
4
4
9
ASSCBL
Add-in SAS/SATA RAID card, No RAID
(PERC H200)
1
4
10
ASSR0CBL
Add-in SAS/SATA RAID card, RAID 0 (PERC H200)
2
4
11
ASSR1CBL
Add-in SAS/SATA RAID card, RAID 1 (PERC H200)
2
2
SAS/SSD
RAID
12
ASSR10CBL
Add-in SAS/SSD RAID card, RAID 10
(PERC H200)
4
4
Additional restrictions for RAID configurations are listed as follows:
 Hard drives must be all 3.5” or 2.5”
 Must be all SAS or all SATA or all SSD
 No Mixed Hard drives allowed
 SSD support requires PERC H200
 PERC S300 does not support SSD
The PERC S300 does not support the following virtualization solutions:
 Microsoft
®
Hyper-V
®
server 2008 x64 (download version)
 Microsoft Windows Server
®
2008 x64 (Hyper-V role enabled)
 Microsoft Windows Server 2008 SP2 x64 (Hyper-V role enabled)
 Microsoft Windows Server 2008 R2 (Microsoft Windows
®
7 includes SP2 bits) x64 (Hyper-V
role enabled)
