Monitor Specifications
Flat Panel Specifications
Model S2317HJ
Screen type Active matrix - TFT LCD
Panel type In-plane Switching
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
58.42 cm (23 in)
509.18 mm (20.05 in)
286.41 mm (11.28 in)
1458.34 cm
2
(226.04 inch
2
)
Pixel pitch 0.265 mm
Viewing angle (vertical
/ horizontal)
178° / 178° (typical)
Luminance output 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
8,000,000 to 1 (Dynamic Contrast)
Faceplate coating Low Haze with 3H hardness
Backlight LED edgelight system
Response time 6ms gray to gray (typical)
Color depth 16.78 million colors
Color gamut
82% (typical)
*
*
[S2317HJ] color gamut (typical) is based on CIE1976(82%) and CIE1931(72%) test
standards.
Resolution Specifications
Model S2317HJ
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1920 x 1080 at 60 Hz
