Dell S2421NX User Manual

Operating the monitor | 31
Operating the monitor
Power on the monitor
Press the button to turn on the monitor.
Using the front panel controls
Use the control buttons at the bottom edge of the monitor to adjust the specifications
of the image being displayed. When using the control buttons, an On-Screen Display
(OSD) menu appears on the screen with numeric values.
3 4 51 2

Dell S2421NX Specifications

General

Screen Size	23.8 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	IPS
Refresh Rate	75 Hz
Aspect Ratio	16:9
Brightness	250 cd/m²
Contrast Ratio	1000:1
Connectivity	1 x HDMI 1.4, 1 x VGA
Color Support	16.7 million colors
Response Time	4 ms (gray to gray)
Viewing Angle	178°
Features	Anti-glare
VESA Mount	100 x 100 mm
