Dell S2421NX - Outline Dimension

Outline dimension
15.0
[0.59]
53.8 [2.12]
150.7 [5.93]
5
21
249.0
[9.80]
28.2
[1.11]
407.4 [16.04]
165.4
[6.51]
88.8 [3.50]
409.9 [16.14]
1.8 [0.07]
14.2 [0.56]
527.0
[20.75]
537.8
[21.17]
296.5 [11.67]
322.6 [12.70]
5.4 [0.21]
20.7 [0.82]
5.4
[0.21]
5.4
[0.21]
111.0 [4.37]
412.8 [16.25]
14.0 [0.55]
9.0 [0.36]
44.7
[1.76]
159.4 [6.28]
171.6 [6.76]
152.8
[6.02]
79.9
[3.15]
100.0(2x) [3.94]
122.0 (2x) [4.80]
Unit : mm(inch)
Dimension : Nominal
Drawing : Not to scale
S2421H/HN/NX Outline Dimension
Z=0
Tilt
Z=34.7(1.37)
Z=43.0(1.69)
Z=44.0(1.73)(4x)
M4x10(4x)
