10 │ About your monitor
Back view
Back view without monitor stand Back view with monitor stand
Label Description Use
1 Joystick Use it to control the OSD menu.
2 Function buttons For more information, see Operating
the monitor.
3 VESA mounting holes (100 mm
x 10
0 mm - behind attached
VESA Cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
4 Regulatory label Lists the regulatory approvals.
5 Stand release button Releases stand from the monitor.
6 Barcode, serial number, and
Service T
ag label
Refer to this label if you need to
contact Dell for technical support.
The Service Tag is a unique
alphanumeric identifier that enables
Dell service technicians to identify
the hardware components in your
monitor and access warranty
information.
7 Cable-management slot Organizes the cables when the
cab
les are routed through the slot.
