Dell S2422HG User Manual

Operating the monitor  │  31
Operating the monitor
Power on the monitor
Press the Power button to turn on the monitor.
Using the joystick control
Use the joystick control on the rear of the monitor to make OSD adjustments.
1. Press the joystick button to launch the OSD main menu.
2. Mo
ve the joystick up/down/left/right to toggle between options.
3. Pr
ess the joystick button again to confirm the settings and exit.
Joystick Description
• When the OSD menu is on, press the button to confirm the
selection or save the settings.
• When the OSD menu is off, press the button to launch the OSD
m
ain menu. See Accessing the menu system.

Dell S2422HG Specifications

General

Panel type	VA
Pixel density	93.53 ppi
Backlight type	LED
Display diagonal	23.6 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 165 Hz
Response time (fast)	4 ms
Horizontal scan range	30 - 187 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	598.22 mm
Screen curvature rating	1500R
Viewable size, vertical	293.28 mm
sRGB coverage (typical)	99 %
Display number of colors	16.7 million colors
Viewable size, horizontal	521.4 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AMD FreeSync type	FreeSync Premium
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	37 W
Power consumption (standby)	0.2 W
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	6.2 mm
Bezel width (side)	7.42 mm
Depth (with stand)	189.9 mm
Width (with stand)	533.55 mm
Height (with stand)	450.77 mm
Weight (with stand)	4900 g
Bezel width (bottom)	23.83 mm
Depth (without stand)	88.71 mm
Height (without stand)	323.22 mm
Weight (without stand)	3370 g
