About your monitor 13
Resolution specifications
Horizontal scan range 30 kHz to 187 kHz (automatic)
Vertical scan range 48 Hz to 165 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 165 Hz
Supported video modes
Video display capabilities (HDMI
& Disp
layPort)
480p, 480i, 576p, 576i, 720p, 1080i, 1080p
Color depth 16.7 million colors
Color gamut sRGB 99% (typical)
Connectivity 1 x DisplayPort version 1.2
2 x HDMI ports version 2.0
1 x Headphone out port
Border width (edge of monitor to active area)
Top
Left/Right
Bottom
6.10 mm
7.42 mm/7.42 mm
23.83 mm
Adjustability
Height adjustable stand
Ti l t
0 to 100 mm
-5° to 21°
Dell Display Manager
compa
tibility
Easy Arrange and other key features
Security Security lock slot (cable lock sold separately)
Model S2422HG
Model S2422HG

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S2422HG and is the answer not in the manual?

Dell S2422HG Specifications

General IconGeneral
Panel typeVA
Pixel density93.53 ppi
Backlight typeLED
Display diagonal23.6 \
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range48 - 165 Hz
Response time (fast)4 ms
Horizontal scan range30 - 187 kHz
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal598.22 mm
Screen curvature rating1500R
Viewable size, vertical293.28 mm
sRGB coverage (typical)99 %
Display number of colors16.7 million colors
Viewable size, horizontal521.4 mm
Display brightness (typical)350 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
AMD FreeSync typeFreeSync Premium
DisplayPort version1.2
VGA (D-Sub) ports quantity0
LED indicatorsPower
Tilt angle range-5 - 21 °
Panel mounting interface100 x 100 mm
Input current1 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)37 W
Power consumption (standby)0.2 W
Doesn't containPVC/BFR
Sustainability certificatesRoHS
Front bezel colorBlack
Heavy metals freeHg (mercury)
Market positioningGaming
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Cables includedAC, DisplayPort
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)6.2 mm
Bezel width (side)7.42 mm
Depth (with stand)189.9 mm
Width (with stand)533.55 mm
Height (with stand)450.77 mm
Weight (with stand)4900 g
Bezel width (bottom)23.83 mm
Depth (without stand)88.71 mm
Height (without stand)323.22 mm
Weight (without stand)3370 g
