Dell S2422HG User Manual

About your monitor  │  11
Bottom view
Bottom view without monitor stand
Label Description Use
1 Power connector Connect the power cable (shipped with your
mo
nitor).
2 Security lock slot Secures the monitor with security lock
(
security lock not included).
3 Stand lock feature Lock the stand to the monitor using a M3 x 6
m
m screw (screw not included).
4 HDMI port (HDMI 1) Connect your computer with the HDMI cable.
5 HDMI port (HDMI 2) Connect your computer with the HDMI cable.
6 DisplayPort Connect your computer with the DisplayPort
cab
le (shipped with your monitor).
7 Headphone out port Connect the headphones.
CAUTION: In
creasing the audio output beyond
50% on the volume control or equalizer may
increase the output voltage on the
headphones thereby increasing the sound
pressure levels.

Dell S2422HG Specifications

General

Panel type	VA
Pixel density	93.53 ppi
Backlight type	LED
Display diagonal	23.6 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 165 Hz
Response time (fast)	4 ms
Horizontal scan range	30 - 187 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	598.22 mm
Screen curvature rating	1500R
Viewable size, vertical	293.28 mm
sRGB coverage (typical)	99 %
Display number of colors	16.7 million colors
Viewable size, horizontal	521.4 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AMD FreeSync type	FreeSync Premium
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	37 W
Power consumption (standby)	0.2 W
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	6.2 mm
Bezel width (side)	7.42 mm
Depth (with stand)	189.9 mm
Width (with stand)	533.55 mm
Height (with stand)	450.77 mm
Weight (with stand)	4900 g
Bezel width (bottom)	23.83 mm
Depth (without stand)	88.71 mm
Height (without stand)	323.22 mm
Weight (without stand)	3370 g
