6 │ About your monitor
About your monitor
Package contents
Your monitor ships with the components shown in the table below. If any
component is missing, contact Dell. For more information, see Contact Dell.
NOTE: Some items may be optional and may not ship with your monitor.
Some features may not be available in certain countries.
NOTE: If you are connecting a stand that you purchased from any other
source, follow the setup instructions that were included with the stand.
Component image Component description
Display
Stand riser
Stand base

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S2422HG and is the answer not in the manual?

Dell S2422HG Specifications

General IconGeneral
Panel typeVA
Pixel density93.53 ppi
Backlight typeLED
Display diagonal23.6 \
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range48 - 165 Hz
Response time (fast)4 ms
Horizontal scan range30 - 187 kHz
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal598.22 mm
Screen curvature rating1500R
Viewable size, vertical293.28 mm
sRGB coverage (typical)99 %
Display number of colors16.7 million colors
Viewable size, horizontal521.4 mm
Display brightness (typical)350 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
AMD FreeSync typeFreeSync Premium
DisplayPort version1.2
VGA (D-Sub) ports quantity0
LED indicatorsPower
Tilt angle range-5 - 21 °
Panel mounting interface100 x 100 mm
Input current1 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)37 W
Power consumption (standby)0.2 W
Doesn't containPVC/BFR
Sustainability certificatesRoHS
Front bezel colorBlack
Heavy metals freeHg (mercury)
Market positioningGaming
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Cables includedAC, DisplayPort
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)6.2 mm
Bezel width (side)7.42 mm
Depth (with stand)189.9 mm
Width (with stand)533.55 mm
Height (with stand)450.77 mm
Weight (with stand)4900 g
Bezel width (bottom)23.83 mm
Depth (without stand)88.71 mm
Height (without stand)323.22 mm
Weight (without stand)3370 g
