Dell S2422HG User Manual

4  │ 
Connecting the DisplayPort (DP to DP) cable and power cables . 27
Connecting the HDMI cable (optional) and power cables . . . . . . . 27
Organizing your cables. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Securing your monitor using Kensington lock (optional) . 28
Removing the monitor stand . . . . . . . . . . . . . . . . . . . . . . 29
VESA wall mounting (optional) . . . . . . . . . . . . . . . . . . . . 29
Operating the monitor . . . . . . . . . . . . . . . . . . . . . . . 31
Power on the monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using the joystick control . . . . . . . . . . . . . . . . . . . . . . . . 31
Using the rear-panel controls . . . . . . . . . . . . . . . . . . . . . 32
Using the On-Screen Display (OSD) menu . . . . . . . . . . . 33
Accessing the menu system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
OSD warning message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Vertical extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Self-test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Built-in diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Common problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Product specific problems . . . . . . . . . . . . . . . . . . . . . . . . 57
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
FCC notices (U.S. only) and other regulatory
information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Contact Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
EU product database for energy label and product
information sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Dell S2422HG Specifications

General

Panel type	VA
Pixel density	93.53 ppi
Backlight type	LED
Display diagonal	23.6 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 165 Hz
Response time (fast)	4 ms
Horizontal scan range	30 - 187 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	598.22 mm
Screen curvature rating	1500R
Viewable size, vertical	293.28 mm
sRGB coverage (typical)	99 %
Display number of colors	16.7 million colors
Viewable size, horizontal	521.4 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AMD FreeSync type	FreeSync Premium
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	37 W
Power consumption (standby)	0.2 W
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	6.2 mm
Bezel width (side)	7.42 mm
Depth (with stand)	189.9 mm
Width (with stand)	533.55 mm
Height (with stand)	450.77 mm
Weight (with stand)	4900 g
Bezel width (bottom)	23.83 mm
Depth (without stand)	88.71 mm
Height (without stand)	323.22 mm
Weight (without stand)	3370 g
