Setting up the monitor | 33
Wall mounting (Optional)
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall-
mounting kit.
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1. Place the monitor on a soft cloth or cushion on a stable, at table.
2. Remove the stand. See Removing the stand for details.
3. Use a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. Attach the mounting bracket from the wall mounting kit to the monitor.
5. Mount the monitor on the wall as instructed in the documentation that shipped
with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall-mounting kit with
minimum weight/load bearing capacity of 16.96 kg (37.4 lb).
