Dell S2815dn Installation And Configuration Guide

CACStar User Guide Rev A27
Copyright 2017 Digital Imaging Technology Page 5
Introduction
CACStar™ provides a solution to HSPD-12 requirements for
CAC/PIV based protection of network data to and from printers or
Multifunction Devices (MFDs). You can configure it to require an
authenticated CAC/ PIV card to control Copy, Print, Fax, Scan to
Folder, Scan to Email, SNMP, or FTP.
Configurable authentication methods include Basic X.509 certificate
on the card, PIN validation, expiration, OCSP, root certificate, LDAP,
and Kerberos. CACStar will adopt the IP address of the MFD on
which it is installed, so there is no host network configuration change
necessary.
Configuration is easily done using secure web based access to
CACStar by the network administrator. In its simplest form, the
admin only needs to configure the IP address of the MFD and the IP
address of the local time server. Information about many additional
configuration options is described later in this guide.
Prior to starting the CACStar configuration, you must know your
network infrastructure. Appendix A has a convenient list of questions
and the necessary data that you will need to collect.
If you need help obtaining correct firmware or documentation,
contact the Dell ProSupport Help Desk by calling 1-866-516-3115, or
by sending email to Imaging_Solutions_Support_CAC@dell.com.
This manual will guide you through installing the hardware, installing
the software to convert the Dell S2815dn to be CACStar enabled, and
configuration of the customer desired authentication control
options.

Dell S2815dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Maximum copy resolution	- DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 297 mm
Output color depth	24 bit
Scan speed (color)	17 ppm
Image formats supported	JPEG XR
Maximum scan resolution	9600 x 9600 DPI
Document formats supported	PDF
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	80000 pages per month
Recommended duty cycle	700 - 4000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3
Cabling technology	10/100/1000Base-T(X)
Authentication method	HTTP, HTTPS, TLS 1.2, SNMP (v1 / v2 / v3), MIBv2, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour (mDNS), Telnet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)	IPSEC w/ IPv4
Supported network protocols (IPv6)	IPSEC w/ IPv6
Internal memory	1024 MB
Card reader integrated	No
Sound pressure level (printing)	52.9 dB
Control type	Touch
Product color	Black
Display diagonal	4.3 \
Market positioning	Business
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	900 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Operating altitude	0 - 3100 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	15 - 85 %
Certification	EN 60950-1/IEC 60950-1; EN 55022 (Class B) EN55024 EN61000-3-2 (Class A) EN 61000-3-3 CE Mark (EU) UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada) US CFR Title 47 FCC Part 2 and 15B Part 15C and Part 68 FDA/DHHS (21CFR Chapter 1 Subchapter J RCM (Australia) Telepermit (New Zealand) Singapore Mark SABS/ICASA (South Africa) NOM NYCE (Mexico) GS Mark (Germany) and other certifications required by individual country. WHQL Citrix SAP Novell YES USB Google Cloud Print Mopria AirPrint
Sustainability certificates	Blue Angel, RoHS, ENERGY STAR
AC input voltage	110 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (sleep)	14 W
Power consumption (standby)	52 W
Power consumption (average operating)	610 W

Weight and Dimensions

Depth	556 mm
Width	557 mm
Height	644 mm
