Dell S2817Q User Manual

About Your Monitor | 9
Monitor Specifications
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type TN
Viewable image
Diagonal 70.86 cm (27.90 inches)
Active Area
Horizontal 620.93 mm (24.45 inches)
Vertical 341.28 mm (13.43 inches)
Area 211910.99 mm
2
(328.36 inches
2
)
Pixel pitch 0.16 mm x 0.16 mm
Viewing angle
Horizontal 170° (typical)
Vertical 160° (typical)
Luminance output 300 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
8,000,000 to 1 (dynamic contrast on)
Faceplate coating Anti-glare treatment of the front polarizer (3H)
Backlight LED
Response Time 2 ms typical (G to G)
Color depth 1.0737 G (8 Bits.+ High FRC)
Color gamut 72% of NTSC
Resolution Specifications
Horizontal scan range 31 kHz to 140 kHz (DP/HDMI)
30 kHz to 83 kHz (MHL)
Vertical scan range 50 Hz to 75 Hz (DP/HDMI)
24 Hz to 60 Hz (MHL)
Maximum preset resolution 3840 x 2160 at 60 Hz
Video display capabilities
(DP & HDMI & MHL playback)
480p, 576p, 720p, 1080p

Dell S2817Q Specifications

General

Screen Size	28 inches
Resolution	3840 x 2160 (4K UHD)
Panel Type	TN
Refresh Rate	60 Hz
Brightness	300 cd/m²
Contrast Ratio	1000:1
Aspect Ratio	16:9
VESA Mount	100 x 100 mm
Inputs	1 x DisplayPort, 1 x Mini DisplayPort
Viewing Angle	170° (horizontal), 160° (vertical)
USB Ports	4 x USB 3.0
Power Consumption	45W (typical)
Color Support	1.07 Billion Colors (10-bit)
