4
S3100 Series Technical
Specifications
The following tables describe the technical specifications for the S3100
systems.
CAUTION: Lithium Battery Caution: There is a danger of explosion if
the battery is incorrectly replaced. Replace only with same or
equivalent type. Dispose of the batteries according to the
manufacturer's instructions.
Table 2. S3100 Series Chassis Physical Design
Parameter Specifications
Height 1.71 inches (43.5 mm).
Width 17.09 inches (434 mm).
Depth 16.02 inches (407 mm).
Chassis weight
S3124 — 13.45 lbs (6.1 kg).
S3148 — 13.89 lbs (6.3 kg).
S3124F — 13.45 lbs (6.1 kg).
S3124P — 14.77 lbs (6.7 kg).
S3148P — 15.65 lbs (7.1 kg).
Table 3. Environmental Parameters
Parameter Specifications
Operating temperature 32° to 113°F (0° to 45°C).
Operating humidity 8 % to 85 % (RH), noncondensing.
Storage temperature –40° to 158°F (–40° to 70°C).
S3100 Series Technical Specifications
25
