Dell SE2222H User Manual

Operating your monitor │ 33
Operating your monitor
Turning on the monitor
Press the button to turn on the monitor.
Using the front panel controls
Use the control buttons at the bottom edge of the monitor to adjust the image being displayed.
1
2
3
4
5

Dell SE2222H Specifications

General

Panel type	VA
Color gamut	72 %
Pixel pitch	0.249 x 0.241 mm
Screen shape	Flat
Pixel density	103 ppi
Response time	12 ms
Backlight type	LED
Display diagonal	21.45 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Viewable size, vertical	260.28 mm
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	54.48 cm
Viewable size, horizontal	478.66 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
Headphone out	-
DisplayPorts quantity	0
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (off)	0.3 W
Power consumption (typical)	14.1 W
Package depth	565.91 mm
Package width	129.03 mm
Package height	355.09 mm
Package weight	4400 g
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Cables included	AC, HDMI, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	12.8 mm
Depth (with stand)	178.81 mm
Width (with stand)	504.26 mm
Height (with stand)	384.08 mm
Weight (with stand)	2670 g
Bezel width (bottom)	16.92 mm
Depth (without stand)	49.21 mm
Height (without stand)	295.38 mm
Weight (without stand)	2340 g
