14. Lift the palm rest off the computer base.
Replacing the Palm Rest
1. Follow the instructions in Before You Begin.
2. Route the following cables through the palm rest and connect them to the corresponding connectors on the system board:
l power button cable
l battery indicator cable
l speaker module cable
l touch pad cable
l display cable
l camera/microphone
3. Align the palm rest with the computer base and gently snap the palm rest into place.
4. Replace the four screws on the top of the palm rest.
5. Turn the computer over.
6. Replace the ten screws on the computer base.
7. Replace the keyboard (see Replacing the Keyboard).
8. Replace the hard drive (see Replacing the Hard Drive).
9. Replace the Mini-Cards, if applicable (see Replacing the Mini-Card).
10. Replace the memory modules (see Replacing the Memory Module(s)).
11. Replace the base cover (see Replacing the Base Cover).
12. Replace the battery (see Replacing the Battery).
13. Replace any removed cards in the ExpressCard slot or 8-in-1 Media Card Reader.
