Dell T06G - Page 59

Storage
Storage eMMC 4.5.1 32 GB (HS200) / eMMC 4.5.1 64GB
(HS200)
Battery
Type
2 Series X 1 Parallel (2S1P) Lithium ion
32Wh (Nominal)
Dimensions
Depth 230.64 mm (9.08 inches)
Height 4.71 mm (0.19 inch)
Width 83.3 mm (3.28 inches)
Weight 220.00 g (0.49 lb)
Voltage 7.4 VDC (nominal) and 8.7 VDC (maximum)
Temperature range
Operating
Charge:
0 °C to 50 °C; 32 °F to 158 °F
Discharge:
0 °C to 70 °C; 32 °F to 122 °F
Non-Operating -20 °C to 65 °C; 4 °F to 149 °F
Coin-cell battery 3 V CR1220 lithium ion
Voltage : 3V
Capacity : 35mAh (23+/- 3 degree)
Weight: 0.8g
Temperature : -20 ~ +60 degree.
AC Adapter
Type
Input voltage 100 VAC to 240 VAC
Input current (maximum) 0.60 A
Input frequency 50 Hz to 60 Hz
Output power 23.4 W / 30 W
Output current (30 W) 19.5 V / 1.2 A (Continuous) 19.5 V / 1.53 A (peak
current) ; 5 V / 2 A (Continuous)
Rated output voltage 19.5 Vdc
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-operating –40 °C to 70 °C (–40 °F to 158 °F)
59
