12 | About Your Monitor
Monitor Specifications
Flat Panel Specifications
Resolution Specifications
Model U2415
Screen type Active matrix - TFT LCD
Panel type In Plane Switching
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
611.30 mm (24.1 inches)
518.40 mm (20.41 inches)
324.00 mm (12.75 inches)
167961.60 mm
2
(260.35 inch
2
)
Pixel pitch 0.27 mm x 0.27 mm
Viewing angle 178° (vertical) typical
178° (horizontal) typical
Luminance output 300 cd/m² (typical)
50 cd/m² (minimum)
Contrast ratio 1000 to 1 (typical)
2M to 1 (typical Dynamic Contrast On)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time NORMAL mode: 8 ms grey to grey (typical)
FAST mode: 6 ms grey to grey (typical)
On/Off: 19 ms black to white (typical)
Color depth 16.78 million colors
Color gamut CIE1976 (91%), CIE 1931 (76%), and sRGB coverage 99%
Model U2415
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset resolution 1920 x 1200 at 60 Hz
