Dell Vostro 1014 - Bluetooth Wireless Card; Removing the Bluetooth Wireless Card

Back to Contents Page
Internal Card With Bluetooth®Wireless Technology
Dell™Vostro™1014/1015ServiceManual
Removing the Bluetooth Wireless Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Remove the hard drive.
5. Remove the WLAN card.
6. Remove the control panel cover.
7. Remove the keyboard.
8. Remove the display assembly.
9. Remove the palm rest.
10. Remove the I/O board.
11. Disconnect the Bluetooth card cable from the connector on the system board.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
