Speaker
Dell™Vostro™1014/1015ServiceManual
Removing the Speaker
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the ExpressCard (if applicable).
3. Remove the memory card (if applicable).
4. Remove the battery.
5. Remove the access panel.
6. Remove the hard drive.
7. Remove the memory modules.
8. Remove the WLAN card.
9. Remove the control panel cover.
10. Remove the keyboard.
11. Remove the display assembly.
12. Remove the palm rest.
13. Remove the processor fan.
14. Remove the I/O board.
15. Remove the Bluetooth®wireless card.
16. Remove the system board.
17. Remove the screw that secures the speaker to the computer chassis.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
