Specifications
Dell™Vostro™1014/1015ServiceManual




System Information
Memory
Audio
Battery
5-in-1 Memory Card Reader
Display
Camera (Optional)
Physical
Processor
Communications
Keyboard
Ports and Connectors
Video
Touch Pad
AC Adapter
Environmental
NOTE: Offerings may vary by region. For more information regarding the configuration of
your computer, click Start (or Start in Windows®XP)® Help and Support, and then
select the option to view information about your computer.
 SystemInformation
System chipset
Intel®GM45
Data bus width
64 bits
DRAM bus width
dual-channel (2) 64 bit buses
Processor address bus width
36 bits
Flash EPROM
1 MB
 Processor
Processor type
Intel Core 2 Duo, or Intel Celeron®processors (Socket
P)
L2 cache
3 MB or 6 MB
External bus frequency
667 and 800 MHz
 Memory
Memory module connectors
two DIMM sockets
Memory module capacities
1 (one DIMM), 2 (one DIMM or two DIMMs), or 4 GB (two
DIMMs) capable
Memory type
DDR2/DDR3 800 MHz (Non-ECC only)
Minimum memory
1 GB
Maximum memory
4 GB
 Communications
Modem
Integrated Conexant CX20548-11Z 56kbps modem
Network adapter
10/100/1000 ethernet LAN on system board
Network controller
Realtek RTL8111DL
Wireless
internal support for PCI-e Mini-Card, WLAN: Dell WLAN
5100 or Broadcom WLAN1397_1510
Bluetooth®355 V2.0 and Bluetooth 360 V2.1 wireless
technology (optional)
Camera
optional 1.3MP and associated camera software
Audio
Audio type
two-channel high-definition audio codec (HDA)
Audio controller
Conexant CX-20583-10z
Stereo conversion
24-Bit (stereo digital-to-analog)
24-Bit (stereo analog-to-digital)
Interfaces:

Internal
high definition audio
External
microphone-in connector, stereo headphones/speakers
mini-connector
