Dell Vostro 1014 - Communications and Audio; Keyboard and Battery Specifications; Ports, Connectors, and Memory Card Reader







Speakers
one 2-watt, 4-ohm speaker
Internal speaker amplifier
2-W channel into 4 ohms
Internal microphone
single digital microphone
Volume controls
program menus, keyboard function keys
 Keyboard
Number of keys
105 (U.S. and Canada); 106 (Europe); 109 (Japan)
Layout
QWERTY/AZERTY/Kanji
Size:

Standard
full-sized (19 mm key pitch)
Maximum
359.4 mm x 118.9 mm x 5.2 mm (14.15 x 4.681 x 0.205
inches)
 Battery
Type
4 or 6-cell "smart" lithium ion
Dimensions:
Depth
53.39 mm (2.10 inches)
Height
20.44 mm (0.80 inches)
Width
206.44 mm (8.12 inches)
Voltage:
4-cell
14.8 VDC
6-cell
11.1 VDC
Temperature range:
Operating
0°to35°C(32°to95°F)
Storage
–20°to65°C(–4°to149°F)
Coin-cell battery
CR-2032, 4–year life
 Ports and Connectors
ExpressCard connector
one 34 mm PCI ExpressCard
USB
four USB 2.0-compliant connectors
Video
15-hole connectors
IEEE 1394
4-pin mini
5-in-1 Memory Card Reader
Media card controller
Ricoh R5C847
Connector
3-in-1 combo card connector
Cards supported
SecureDigital (SD)
SDIO
MultiMediaCard(MMC)
Memory Stick
Memory Stick PRO
 Video
Video type
integrated
Video controller
Intel GM45
Video memory
System
Memory
Dynamic Video Memory Technology
(DVMT)
1 GB
512 MB
2 GB
782 MB
3 GB
1294 MB
4 GB
1550 MB
LCD interface
LVDS
TV support
VGA connector
