Fingerprint Reader
Dell™Vostro™1320ServiceManual
Removing the Fingerprint Reader
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery from the computer.
3. Remove the hard drive from the computer.
4. Remove the WLAN card from the computer.
5. Remove the fan from the computer.
6. Remove any ExpressCards from the computer.
7. Remove the hinge cover from the computer
8. Remove the keyboard from the computer.
9. Remove the display assembly from the computer.
10. Remove the palm rest from the computer.
11. Open the fingerprint reader cable retaining clip.
12. Open the fingerprint reader cable retaining clip.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
