Dell Vostro 1320 - Page 7





connector
IEEE 1394
One 4-pin connector
Dock
Optional USB Port Replicator only
Mini-card support (internal expansion slots)
One dedicated half Mini-Card slot for WLAN
One dedicated full Mini-Card slot for WPAN (Bluetooth®
or ultra wideband [UWB])
WPAN full Mini-Card slot can also be used for the Intel
Flash Cache
Modem
Optional USB external modem
Network adapter
RJ-45 connector
USB, USB PowerShare, eSATA
Four 4-pin USB 2.0-compliant connectors
Video
VGA
 Communications
Modem
External (optional)
Network adapter
10/100/1000 Ethernet LAN on system board
Wireless
WLAN half Mini-Card, WPAN full Mini-Cards, Bluetooth
wireless support, and UWB technology
Mobile Broadband
None
GPS
None
 Video
Video type
Integrated
Discrete on system board, hardware accelerated
Video controller
Integrated video: Mobile Intel GMA X4500
Discrete video: NVIDIA GeForce 9300M GS
Data bus
Integrated video or PCI-Express video x16
Video memory
Integrated video: up to 256 MB shared
Discrete video: 256 MB dedicated memory
Video output
Video connector and multimode DisplayPort
Audio
Audio type
Two-channel high definition audio codec
Audio controller
IDT 92HD71B5
Stereo conversion
24-Bit (stereo digital-to-analog)
24-Bit (stereo analog-to-digital)
Interfaces:

Internal
Internal High Definition Audio
External
Microphone-in connector, stereo headphones / speakers
mini-connector
Speaker
One 2-watt, 4-ohm speakers
Internal speaker amplifier
1-Watt channel into 4 ohms
Internal microphone
Single digital microphone
Volume controls
Volume control buttons
Display
Type (active-matrix TFT)
13.3" WXGA anti-glare CCFL
13.3" WXGA TrueLife CCFL
Dimensions
Height
178.8 mm (7.03 inches)
Width
286.08 mm (11.26 inches)
Diagonal
337.82 mm (13.3 inches)
Maximum Resolutions
WXGA
1280 x 800 at 262 K colors
WXGATrueLife
1440 x 900 at 262 K colors
Operating angle
0°(closed)to130°
Refresh rate
60 Hz
Viewing angles
