Dell Vostro 3300 - Display Panel; Removing the Display Panel

Back to Contents Page
Display Panel
Dell™Vostro™3300ServiceManual
Removing the Display Panel
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the keyboard.
7. Remove the wireless local area network (WLAN) card.
8. Remove the wireless wide area network (WWAN) card.
9. Remove the palm rest.
10. Remove the display assembly.
11. Remove the display bezel.
12. Remove the screws that secure the display panel to the display assembly.
13. Carefully lift the display panel from the display assembly.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
