Dell Vostro 3300 - Palm Rest; Removing the Palm Rest

Back to Contents Page
Palm Rest
Dell™Vostro™3300ServiceManual
Removing the Palm Rest
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the wireless local area network (WLAN) card.
7. Remove the keyboard.
8. Remove the wireless wide area network (WWAN) card.
9. Remove the rubber feet at the bottom of the computer.
10. Removethescrewsthatsecurethepalmresttothebottomofthecomputer.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
