Bluetooth Card
Dell™Vostro™3300ServiceManual
Removing the Bluetooth Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the wireless local area network (WLAN) card.
7. Remove the keyboard.
8. Remove the wireless wide area network (WWAN) card.
9. Remove the palm rest.
10. Lift the Bluetooth
®
card up and away from the system board.
Replacing the Bluetooth Card
To replace the Bluetooth card, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
