Display Assembly
Dell™Vostro™3500ServiceManual
Removing the Display Assembly
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the wireless local area network (WLAN) card.
7. Remove the wireless wide area network (WWAN) card.
8. Remove the keyboard.
9. Remove the palm rest.
10. Flip the computer over and release the antenna cables from their routing guides on the computer.
11. With the right side of the computer facing up, disconnect the display cable from the system board.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
