ExpressCard Cage
Dell™Vostro™3500ServiceManual
Removing the ExpressCard Cage
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the keyboard.
7. Remove the palm rest.
8. Remove the ExpressCard, if applicable.
9. Remove the screw that secures the ExpressCard cage to the computer.
10. Open the clip that secures the ExpressCard cage cable to the computer.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
