Display Bezel
Dell™Vostro™3500ServiceManual
Removing the Display Bezel
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the wireless local area network (WLAN) card.
7. Remove the wireless wide area network (WWAN) card.
8. Remove the keyboard.
9. Remove the palm rest.
10. Remove the display assembly.
11. Using a plastic scribe, gently pry under the display bezel to release it from the display assembly.
12. Lift the display bezel and remove it from the display assembly.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
