Processor Heat Sink and Fan Assembly
Dell™Vostro™430ServiceManual
Removing the Processor Heat Sink and Fan Assembly
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the Cover.
3. Disconnect the processor heat sink and fan assembly cable from the system board.
4. Using a Phillips head screwdriver, loosen the four captive screws that secure the processor heat sink and fan assembly to the system board.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
